Sony ECM-44B
Lavalier Microphone

Sony's ECM-44 is an affordable, general voice model that provides good sound quality and is widely used in business presentation systems and TV production. The ECM-44 is available in four versions, featuring different connector types. This model, ECM-44B, is the XLR version with power barrel for use as a wired microphone.
Convenient to use
The ECM-44 is an affordable alternative to the traditional hand held microphone and being 'hands free' it allows the presenter to concentrate on her/his performance.
Professional image
Either 'in front of camera' or at a business presentation the ECM-44 creates a professional and tidy image.
Easy to use
It can often be difficult to achieve good quality voice pick-up but the ECM-44 can help get good results. The microphone's capsule is designed for general voice pick-up with a mid-frequency emphasis characteristic and a suitable frequency response.

• Capsule type: Electret Condenser
• Frequency response: 40(15,000Hz
• Directivity: OMNI
• Microphone cable: 3m
• Output connector: XLR-3-12C TYPE
• Battery: SUM-3(NS)(1.5V)
• Ext. power: ---
• Dynamic range: equal to or greater than (90dB)
• Signal-to-noise ratio (A weighted, 1kHz, 1 Pa.): equal to or greater than (62dB)
• Inherent noise (0dB SPL =20(Pa.): equal to or less than(32dB SPL)
• Wind noise (w/wind screen): equal to or less than(40dB SPL)
• Maximum input sound pressure level: 122dB SPL
• POWER SUPPLY:
• Battery life: Approx. 5,000H
• Sensitivity (0dB=1V/Pa,at 1kHz): -53.0dB(3dB)
• Output impedance at 1kHz: 250ohms +/-20% (Balanced)
